Temporoc

Multi-Purpose Mixed-Signal SiPM read-out ASIC

Description

Temporoc is a 64-channel front-end ASIC designed to readout silicon photomultipliers (SiPMs) for particle time-of-flight measurement applications. Temporoc combines a very fast and low-jitter trigger with accurate charge and time measurements. Energy and time are digitized internally with a 10-bit ADC and 50ps-bin TDC. In total, Temporoc is capable of providing two distinct time tagging and two energy measurement of each event.

The concept of this ASIC is combining two measurement lines that won’t interfere one with each other to measure both first incident photon timing measurement and whole crystal light charge integration. Additionally, Temporoc features clustering triggers readout which could be useful for particle detection with monolithic scintillator.

An adjustment of the SiPM high voltage is possible using a channel-by-channel input DAC.  It allows a fine SiPM gain and dark noise adjustment at the system level to correct for the non-uniformity of SiPMs.

The power consumption is 5 mW/channel. Temporoc is suitable for any application that requires both accurate time resolution and precise energy measurement such as time-of-flight gamma detection.

Parameters

ParametersValue
TRLTechnology Readiness Level 4 - ASIC validated in lab environment
Available versions
  • Discontinued
  • Active
Detector Read-Out SiPM
Number of Channel64
Signal Polarity Positive
SensitivityTrigger on first photo-electron
Timing Resolution 20 ps rms (TBC)
Dynamic Range3000 photo-electrons (106 SIPM gain), Integral Non Linearity: 1% up to 2000 ph-e
Packaging & Dimension

BGA (20x20mm, 500 balls – TBC)

Power Consumption Power supply: 1.2V, 330 mW
Inputs 64 voltage inputs with DC adjustment for SiPM HV tuning
Outputs
  • Digital output (dual ADC and dual TDC per channel) – selectable transmission mode.
  • 1 multiplexed time trigger output
  • 2 ASIC trigger 0R outputs (64 channels, 2 levels)
Internal Programmable Features
  • 64 HV adjustment for SiPM (64x8bits)
  •  time trigger threshold adjustment (10bits)
  • charge measurement tuning
  • ADC Peak Sensing, 64 trigger masks
  • internal temperature sensor
  • channel by channel output enable
  • trigger latch
  • programmable data output
Evaluation systems

Evaluation board : 64 channels - available

Diagram

Temporoc is a GenerIC family IC

GenerIC is a new read-out chip family by Weeroc. GenerIC features fast flip-chip packaged integrated circuits pin-to-pin compatible one with another. Changing detector and its front-end electronic become straightforward with GenerIC family. Pin to pin compatibility allow keeping the same front-end electronics and change detector and front-end ASIC while keeping downstream data stream identical. GenerIC makes easy multi-detector read-out by having a common read-out scheme independant of the detector. Temporoc is the only GenerIC read-out-chip with a fully digital output, nvertheless, compatibility of digital pin and input are preserved with other analogue generIC chips. Check the GenerIC family :

Evaluate Temporoc

Use our open source evaluation system to build your proof of concept. Our evaluation systems are fully open. We provide the schematic that can be used as a reference design, we provide an open source firmware coded in VHDL and an open source software coded in Python.

Weeroc evaluation system features 64 channels of read-out electronics, input is a convenient HE10 connector allowing simple interface with detectors. Output is USB to a computer. Software and firmware allow easy and user-friendly programming of Temporoc simple calibration and straight-forward data acquisition.
